ZKteco TBM Parking Ticket dispenser

Key Features

• Microwave radar for hands-free ticket dispensing

• High-precision 2D barcode scanner

• Thermal ticket printer

• Supports IC/ID/UHF cards (optional)

• Loop detection or radar trigger

• LED status indicators

• TCP/IP + Wiegand communication

• Robust cold-rolled steel, IP65 rating

Technical Specifications

• Model: TBM 01 (Entrance)

• Dimensions: 288 × 360 × 1380 mm

• Weight: 32 kg

• Material: Cold-rolled steel

• Protection: IP65

• Voltage: AC 220V

• Power: 100W (max) / 50W (min)

• Temperature: -15°C to +55°C

• Humidity: ≤90% (non-condensing)

• Ticket Capacity: ~800 sheets/roll

• Records: 10,000 entry/exit

• Allowlist/Blocklist: 1,000 each

• Monthly Capacity: 8,000

Integration

Works with ZKTeco parking software, barrier gates, and central payment systems. Supports offline operation.

Notes

TBM 01 = Ticket Entry Dispenser (TBM 02 typically Exit). Specs may vary by configuration.
